Most writing about spot UV explains why it looks good. Less of it explains what separates a panel where the effect lands from one where it does not.

That difference comes down to a short list of decisions, and all of them are made before the press runs.

Arkay Packaging is a folding carton manufacturer that finishes cartons with inline aqueous coating, inline flexo specialty coating for pearlescent, gold and silver effects, foil stamping, and embossing held to ±0.3mm registration.

This is the version that covers the decisions.

What spot UV coating in packaging is

Spot UV coating in packaging is a gloss coating applied to selected areas of a printed carton rather than across the whole surface. The effect comes from the difference: a glossy element against a matte or uncoated ground reads as raised and deliberate, even though the height difference is slight.

It is called UV because the coating cures under ultraviolet light rather than drying by evaporation. Curing that way makes it hard and sets it fast, which is what allows a distinct, sharp-edged coated area.

Because the coating only goes in certain places, it needs a mask: a separate layer in the artwork file defining exactly where coating lands. That mask usually means an additional operation, which is the practical fact behind several of the trade-offs below.

Spot UV, spot gloss, spot varnish: key differences

These three get used as synonyms and are not the same thing. Worth being precise, because the differences show up on a folding carton.

• Spot UV is cured under ultraviolet light. It sits harder and slightly higher, with the most pronounced gloss and the sharpest edge.
• Spot varnish is ink-based and applied on press. It sits flatter, with a softer sheen and a less defined edge.
• Spot gloss describes the visual outcome rather than a process, so it can mean either of the above.

When specifying, name the process rather than the effect. The differences in height, hardness and behavior on a fold are real, and “we want spot gloss” leaves all three unresolved.

What decides the result

• Contrast — the effect exists only against matte or uncoated ground. On a glossy panel there is nothing for it to play against.
• Scannable codes — gloss flattens the contrast a phone camera reads, so keep coating off any code.
• Folds — a hard coating over a crease can craze, so keep it clear of tight folds.
• Registration — the coated area registers to the artwork beneath it, so allow tolerance rather than assuming a perfect edge.
• Coverage and route — coverage and coating choice decide the recycling question. Whether it runs inline or as a separate pass is a question for your manufacturer.

Three of those are reasonably intuitive. Two are where projects actually come unstuck.

The QR code problem

This is the one discovered latest and most expensively.

A phone reading a code needs to distinguish dark modules from light gaps. A gloss coating creates specular reflection, meaning the surface bounces light straight back at the camera rather than scattering it, and glare flattens exactly the contrast the camera is looking for.

The sequence that causes it is ordinary. Artwork gets approved, including a code that scans perfectly on an uncoated proof. Finishing is specified afterwards, often by someone else, often as a panel-level instruction: gloss across the front. The code is now under gloss and nobody re-tested it.

The fixes are simple at the right moment: knock the coating out over the code, use a matte or aqueous finish in that area, or move the code to an uncoated panel. All three are straightforward at die-line stage and unavailable after a run. There is more on this in our piece on QR codes on packaging.

The recyclability myth

The claim you will meet most often is that UV coating makes a carton unrecyclable. That is not what the industry guidance says, and the difference matters if a retailer is asking you for evidence.

The reference is the American Forest and Paper Association’s Design Guidance for Recyclability, which assesses how non-fiber elements affect recycling. It rates UV and electron-beam cured inks as not adversely impacting the recyclability of bleached paperboard cartons, the grade most folding cartons are printed on. Worth being precise about the limit: that rating covers cured inks rather than coatings and varnishes, so it is not a blanket clearance for every UV product. It does undercut the idea that curing under UV is inherently the problem.

What the guidance is clear about is the mechanism. A non-fiber element becomes a recycling challenge when it slows the pulping process, plugs screening systems, or leaves residue on the finished board. Coverage and coating choice decide that, not the presence of UV as a category.

There is no single yes or no available, and anyone offering one is overstating. AF&PA found mill thresholds vary widely, and fewer than half the mills it surveyed would give a figure at all. So the useful step is confirming your specific coating and coverage against the grade you are running. Aqueous coating is often specified where a recyclability requirement is explicit, and Arkay runs it inline on the same press pass. Our overview of recyclability covers the wider picture.

When the contrast earns the coating

None of the above is a reason to avoid spot UV. It is a set of decisions, and there are jobs where the effect clearly earns its place.

It earns its place when the surrounding area is matte or uncoated, so the coated element has something to play against. Contrast is the entire mechanism, and a glossy element on an already glossy panel achieves very little.

It also earns its place when the effect is doing structural work in the design rather than decorating it: a logo or a single graphic element carrying the whole visual hierarchy, where the difference between coated and uncoated is what the eye follows.

It is harder to justify on a busy layout, on a carton that has to fold tightly through the coated area, or on a panel carrying a scannable code. That is a list of conditions, not a verdict.

When another finish fits the brief better

Gloss is one way to make an element stand out, and it is not always the one the brief is really asking for. The useful move is to specify the effect you want and let the manufacturer propose the method.

Inline aqueous coating delivers a controlled finish on the same press pass, and it is repulpable. Where the brief is really asking for a tactile difference rather than shine, this is often the more sensible answer.

Inline flexo specialty coating produces pearlescent, gold and silver effects. Arkay runs two double flexo coaters connected to the main press, so these are inline rather than a separate operation.

Foil stamping is the route when the brief actually wants reflectivity rather than gloss. It is a different material and a much stronger effect.

Embossing and debossing held to ±0.3mm registration is the route when the brief wants something the hand notices rather than something the eye catches. Often what a client means by “premium” is tactile, not shiny.

Paint on Press is worth knowing about if the job involves several finish variants, since it supports up to 20 variations.

Soft-touch lamination is a separate decision with its own trade-offs, covered in its own piece. All of this applies to standard folding cartons as much as to a flagship launch, and our cosmetics packaging work is where finish decisions tend to matter most.

Describe the effect, not the process

Spot UV works by contrast, so it needs something to contrast against. Where that holds and the coating stays clear of tight folds and scannable codes, it does what it promises, and the recycling question comes down to coverage rather than to UV as a category.

Where the brief is really asking for something else, describe the effect you want rather than the process you have heard of, and let the manufacturer tell you which route gets there.

The cheapest way to settle a finish argument is to hold the finish. Our design studio produces physical mock-ups typically within a week, which is early enough to change a coating decision rather than confirm one. Send us the panel and we will show you the contrast on the actual substrate.
